Description
The Extreme Networks Summit X440-24p, part number 16504, is a stackable, managed Gigabit Ethernet switch designed for enterprise access networks and converged voice, data, wireless, and security deployments. It provides 24 fixed 10/100/1000BASE-T Ethernet ports with IEEE 802.3af/802.3at PoE+ support, allowing compatible IP phones, wireless access points, surveillance cameras, and other powered devices to receive both network connectivity and electrical power over Ethernet.
The switch also provides four unpopulated SFP interfaces supporting 100BASE-FX and 1000BASE-X optical connectivity. Ports 21–24 are shared copper/SFP combination ports, allowing either the corresponding RJ45 or fiber interface to be used.
The X440-24p supports ExtremeXOS software, SummitStack stacking, Layer 2/Layer 3 switching capabilities, VLANs, Quality of Service (QoS), network management, and enterprise resiliency features. It is designed as a 1U rack-mountable switch and includes an internal AC power supply.
Key Features
• 24 × 10/100/1000BASE-T RJ45 Ethernet ports
• PoE+ support on all 24 copper ports
• IEEE 802.3af/802.3at PoE/PoE+ support
• Up to 30 W PoE power per port
• 380 W total PoE power budget
• 4 × unpopulated SFP interfaces
• SFP support for 100BASE-FX and 1000BASE-X
• Four shared RJ45/SFP combination ports on ports 21–24
• 2 × high-performance SummitStack stacking ports
• Ethernet management port
• RJ45 serial console port
• Internal AC power supply
• Optional external redundant power connection via EPS-C2
• ExtremeXOS operating system support
• Managed Gigabit Ethernet switching
• Rack-mountable 1U form factor
Technical Specs
Manufacturer: Extreme Networks
Product Family: Summit X440
Model: Summit X440-24p
Part Number: 16504
Product Type: Managed Ethernet Switch
Switching Technology: Gigabit Ethernet
Ethernet Ports: 24 × 10/100/1000BASE-T RJ45
PoE Ports: 24
PoE Standard: IEEE 802.3af / 802.3at
Maximum PoE Output: Up to 30 W per port
Total PoE Budget: 380 W
Fiber Interfaces: 4 × SFP
SFP Standards: 100BASE-FX / 1000BASE-X
SFP Configuration: Four shared combination ports with RJ45 ports 21–24
Stacking: SummitStack
Stacking Ports: 2
Management Interface: Ethernet management port
Console Interface: RJ45 serial console
Power Input: 100–240 VAC
Frequency: 50–60 Hz
Maximum Input Current: 6.0 A
Power Consumption with PoE: 585 W
Power Consumption without PoE: 37 W
Form Factor: 1U rack-mountable
Additional Identification: 800472-00-13
MAC Address: 000496986F55
