Description
The Alcatel‑Lucent OmniSwitch OS6450‑U24S is a enterprise‑grade managed Layer 3 network switch designed for campus, branch office, and mid‑sized business environments. It comes in a 1 U rack‑mount form factor and delivers high performance with flexible port options using SFP and SFP+ modules for fiber and uplink connectivity. The switch supports advanced security, routing, VLAN segmentation, and stacking capabilities, making it suitable for demanding network edge and distribution layer roles.
Key Features
-
Manufacturer: Alcatel‑Lucent / Nokia
-
Model: OS6450‑U24S
-
Device Type: Managed Layer 3 Gigabit Ethernet Switch
-
Form Factor: 1 U rack‑mountable
-
Managed: Yes (Layer 2/Layer 3)
-
Stackable: Up to 8 units combined
-
Ports:
-
22 × Gigabit SFP fiber ports
-
2 × combo ports configurable as Gigabit copper or SFP
-
2 × fixed SFP+ ports for 1 Gb/s/10 Gb/s uplinks
-
-
Expansion: 1 expansion slot for optional uplink/stacking modules
-
Use Cases: Campus core/distribution, service provider access, enterprise edge
Technical Overview
-
Switching Capacity: 128 Gbps aggregate
-
Forwarding Rate: ~95.3 Mpps
-
Stacking Bandwidth: Up to 40 Gbps
-
VLANs Supported: Up to 4000
-
Routing: IPv4 and IPv6 static, RIP, RIPng support
-
MAC Address Table: ~16,000 entries
-
Jumbo Frame Support: Up to 9216 bytes
-
Management / Security: SNMP (v1/2/3), CLI, SSH, RADIUS, TACACS+, LDAP, HTTPS, IPv6 aware
